C-14 Barcode Reader
For scanning Barcode
For scanning RFID
Users can customize the JADAK barcode reader based on specific requirements
or contact the Mindray service engineers. This configuration guide is applicable
for the Ultrasound System only.
Setting Up the JADAK Barcode Reader (Taking HS-1R as an Example)
1. Turn off the power to the Ultrasound System;
2. Connect the appropriate interface cable to the barcode reader;
3. Plug the other end of the cable into a free USB port on the Ultrasound system;
4. Once the imager has been fully connected, power on the Ultrasound System.
