6. Operating | 6.2 - Configuration and adjustment via the keypad | 134
6.2.14.2 Configuring the serial interface for the remote display
1. Press and hold for 2–3 seconds.
SEtuP appears on the display.
2. Press "OK".
Cd 000 appears on the display (Cd flashes).
3. Press (9×) to select SI 071.
4. Press "OK".
rEMdSP appears on the display.
5. Select the individual parameters and modify if required, see Chapters
Parameter table (setup) and Selecting parameters.
[Interface] Port
Selection: none nonE, RS-232 rS232, RS-485 rS485
[Baud rate] bAud
Baud rate of the data transfer
Selection: 1200, 2400, 4800, 9600 (default), 19200, 38400
Only with RS-485: [Mode] ModE
Selection: [Half duplex] HALF, full duplex FuLL
6. Press "Exit" to exit the setup menu.
7. Save the changes.
6.2.14.3 Configuring the serial interface for SMA
1. Press and hold for 2–3 seconds.
SEtuP appears on the display.
2. Press "OK".
Cd 000 appears on the display (Cd flashes).
3. Press (10×) to select SI 072.
4. Press "OK".
SMA appears on the display.
5. Select the individual parameters and modify if required, see Chapters
Parameter table (setup) and Selecting parameters.
