Minebea Intec PR 5310/12 User Manual

4. Device installation | 4.3 - Hardware construction | 38
Weight indicator terminal
Terminal
contact
Connection Description Color
M+ + Meas. + Signal/LC output green
M- – Meas. – Signal/LC output gray
V+ + Supply + Supply/excitation red
S+ + Sense + Sense white
S- – Sense – Sense black
V- – Supply – Supply/excitation blue
Note:
The colors listed here apply for the MinebeaIntec products.
Color code
bk = black
bu = blue
gn = green
gy = gray
rd = red
wh = white
For additional information on the connection, refer to the corresponding
technical documentation.
Note: All components are only shown schematically.
