4. Device installation | 4.3 - Hardware construction | 80
Module status (MS)
LED status Description Comments
Off Module is uninitialized
– No power
– Module has the status "SETUP" or
"NW_INIT".
Constant green Module is initialized Normal operation
1Hz flashing green Error after test Error occurred after test.
2Hz flashing green This is used for node identification in
the network.
Constant red Exception error
– Module has the status "EXCEP
TION"
– The exception error monitoring
system closes all open connec
tions to the module.
1Hz flashing red Configuration error Expected identification deviates from
the available identification.
2Hz flashing red IP address error IP address was not defined.
3Hz flashing red Device name error Device name was not defined.
4Hz flashing red Internal error Module has caused an unrecoverable
internal error.
