5.2.4. Hop Mode Functions
#
Name
Descriptions
18 Hop mode
When selected, allows setting a table of user defined attenuation and dwell time which the
attenuator will "hop" through.
19
Channel selection
Enables hop sequence for selected channels.
20 Hop parameters
Define attenuation levels separately for each selected channel & dwell time for all selected
channels in hop mode.
21 Save / Recall
(Available in Hop mode only) allows clearing all current settings, opening a file of saved
settings or saving current settings.
5.2.5. Sweep Mode Functions
#
Name
Descriptions
22 Sweep mode
When selected, allows setting an attenuation sweep with user defined start, stop, step and
dwell time values.
23
Channel selection
Enables sweep for selected channels.
24
Step
Defines the attenuation step in (minimum according to model).
25
Dwell time
Specifies the time the selected channels will hold each attenuation state.
26
Start / Stop
Define attenuation range for a given channel.
