2.4. Model Selection Guide
Model name
Num. of
Channels
Frequency
range (MHz)
Atten.
range (dB)
Attenuation
resolution (dB)
Max input
power (dBm)
Control protocols
RC8DAT-8G-95
8
1-8000
95
0.25
+28
USB, HTTP, Telnet, SSH
RC4DAT-8G-95
4
1-8000
95
0.25
+28
USB, HTTP, Telnet, SSH*
RC4DAT-8G-120H 4 200-8000 120 0.05 +23
USB, HTTP, Telnet, SSH,
Daisy-chain
RC4DAT-6G-95
4
1-6000
95
0.25
+23
USB, HTTP, Telnet, SSH*
RC4DAT-6G-60
4
1-6000
63
0.25
+23
USB, HTTP, Telnet, SSH*
RC4DAT-6G-30
4
1-6000
30
0.25
+23
USB, HTTP, Telnet, SSH*
For detailed model performance, data and graphs, outline drawing, ordering information and environmental specifications click
on the model part number.
For setup and control instructions for the different control protocols see chapter 4 -.
* SSH support is a new addition, refer to table in section 5.8 for the serial number range which supports this feature.
2.5. Environmental Specifications
Mini-Circuits’ programmable attenuators are intended for operation in office, laboratory, or production test environments. Do
not use in any condition which exceeds the published environmental specifications.
Condition
Specification
Operating temperature
0°C to +50°C
Humidity
5% to 85% RH (non-condensing)
Altitude
Up to 2000 m (6560 ft.)
Pollution degree
2 - Normally only non-conductive pollution occurs (per IEC 61010)
