MIOX RIO Series Operators Manual
P/N: 102-00076-G Page 15
Figure 3 RIO Series OSG Compartments
System Description
The RIO Series OSG is made up of six compartments, Controls, Switch Gear, Power Supply,
Cooling, Plumbing, and Cell (Figure 3).
Cell
Power Supply
Switch Gear
Cooling
Controls
Plumbing
