MIOX RIO Series Operators Manual
P/N: 102-00076-G Page 65
Figure 33 Switch Gear Panel Components
Table 15 Switch Gear Panel Components
Label Component Label Component Label Component
CB1 Breaker PM Power Monitor TPM 1,2,3 Transient Surge Module
DS Switch Disconnect PS Power Supply FH1 Fuse
CN Contactor RLY Safety Relay
DB 1,2,3 Distribution Block GB1, 2 Ground Block
