Mircom TX3-200-4U-C - Universal Slim-Line Enclosure Installation

Enclosure Installation
TX3 Telephone Access System Installation and Operation Manual 23
2.2.2 Installing the Universal Slim-line enclosure
Figure 4. TX3-200-4U-C, TX3-1000-4U-C, TX3-2000-4U-C Dimensions
The Universal enclosure mounts inside the wall with or without the Slim Line
Universal Series Flush Trim Ring TX3-USFT. The Trim Ring houses the
universal series enclosure as shown in figure 6.
422mm
16
5
8
"
86mm
3
3
8
"
149mm
5
7
8
"
394mm
15
1
2
"
386mm
15
3
16
"
28mm
1
1
8
"
11mm
R
7
16
"
14mm
R
9
16
"
114mm
4
1
2
"
87mm
3
7
16
"
