52 TX3 Telephone Access System Installation and Operation Manual
Lobby Control Unit Setup
4.7 Wiegand Output Module
The TX3-WIEGAND-OUT Wiegand Output Module connects to the Lobby
controller board. A Telephone Access panel or Touch Screen with the Wiegand
Output Module installed can send a facility code and a card code to a third-party
access control system. The output sent is shown in Table 2.
The module has Wiegand connector and a ribbon cable. The ribbon cable
connects to the P4 connector on the Lobby controller board.
For a description on how to install the module, see the TX3-WIEGAND-OUT
Installation Instructions LT-6682.
4.8 Guard Phone Module
The TX3-GPM Guard Phone Module mounts above the TX3 Lobby Control
Unit main board on the top left hand side. See figure 20.
Note: The Guard Phone Module works only on NSL systems.
The module has two connectors, an RJ-11 connector and a ribbon cable as shown
in figure 30.
Table 2: TX3-WIEGAND-OUT Output
Event Facility Code Card Code
Access is granted by the
resident after a visitor
calls
167 Dial code associated with the
resident
Access is denied by the
resident after a visitor
calls
168 Dial code associated with the
resident
Access is granted by a
keyless code
169 Dial code associated with the
resident whose keyless code
is used
