76 TX3 Telephone Access System Installation and Operation Manual
NSL Relay Cabinet Installation and Wiring
Figure 40. 2012 NSL Relay Board
P1
P2
This connector mounts
into the NSL backplane
Amphenol connection
from telephone company
LEDs
