NSL Relay Cabinet Installation and Wiring
TX3 Telephone Access System Installation and Operation Manual 73
2. Using a jumper, set the backplane number across the Backplane Number
Selection pins as shown in figure 39.
Figure 39. Backplane Number Section
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Jumper Setting
Backplane Number
Selection
