Typical Network Configurations
Configuration D: MXe Typical Voice and Data Network
Figure 126: MXe Voice and Data Configuration Example
IP Address 192.168.1.2
Subnet 255.255.255.0
Gateway (Router) 192.168.1.1
Layer 2 192.168.1.3
Tip: If an IP Address is on the IP Network List in the IP Routing form,
then the connection will be routed to 192.168.1.1 (router).
If the IP Address is not on the IP Network List, then the connection
will be routed to the WAN Port automatically.
