37
Initial Setup
Verify the Operation of the Controller
1. On the Maintenance PC, access the System Administration Tool.
2. In the System Hardware Profile folder, verify that the information in
each of the forms is correct, including the IP address of the E2T for the
MXe system.
3. In Maintenance and Diagnostics, click Alarm Details.
Verify that the following alarms do not appear (if you get an alarm, go
to “Check Alarm State” on page 117):
- E2T Com (not applicable to the AX, CX/CXi, and CX II/CXi II
controller)
- DSP
4. Connect two IP Phones directly to the controller’s Ethernet ports.
5. Program the IP Phones (refer to the System Administration Tool
Online Help for details).
6. Make a call from one phone to the other.
7. Disconnect the IP Phones from the controller.
Tip: The next four steps are optional.
