66
3300 ICP Technician’s Handbook
Installing a DNIC Music on Hold/Paging Unit (DMP)
To install DNIC Music on Hold (not supported on the AX, CX/CXi,
CX II/CXi II, MXe, or SX-200 Bays):
1. Install a DNI line card in a peripheral card slot.
2. Attach the circuit tip and ring leads to the 25th pair of the DMP.
3. Attach the balanced music source to the 7th pair of the DMP via the MDF.
To install a DMP for Paging (not supported on the AX, CX/CXi, CX II/CXi II
or MXe):
1. Install a DNI line card.
2. Attach the circuit tip and ring leads to the 25th pair of the DMP.
3. Attach the paging adapter interface to the 9th pair of the DMP.
4. If required, attach the page control inputs of the paging adapter via the
MDF to the 11th and 12th pair of the DMP.
5. Connect the paging adapter to an appropriate power source
(according to the manufacturer’s instructions).
6. Connect the external speakers as required to the paging adapter via
the MDF (according to the manufacturer’s instructions).
Program 5485 IP Paging Unit
To program a 5485 IP Paging Unit (this programming procedure provides
a burst of ringing prior to the speech broadcast):
1. Launch the System Administration Tool.
2. In the Multiline IP Sets form
- Program the IP Paging Unit as "5010 IP".
Tip:To reduce the risk of hum or other interference, install the DMP close to
the music source or paging amplifier and keep the cables to and from the unit
as short as possible. If “none” balanced input or output equipment is used,
you may need a balancing transformer (not supplied by Mitel).
Tip:Refer to the 3300 ICP Hardware Technical Reference Manual for
connector pinouts.
Note: See Table 46 for the paging unit pinout and Figure 119 on page
266 for the cross connection wiring.
