Configuring Softkeys
111
Expansion Module Keys
7. Select from Key 1 through Key 16 (M680i) or Key 84 (M685i).
8. In the Line field, select a line for which to apply this key. Valid values are:
• global
• 1 through 24
9. In the BLF List URI field, enter the name of the BLF list defined on the BroadSoft Broad-
Works Busy Lamp field page for your particular user. For example, sip:9@192.168.104.13.
10. Click Save Settings.
Note: The Value field is not required. The BroadWorks BLF/List name is configured in
the BLF List URI field instead.
Note: Contact your System Administrator for the BLF List URI.
