Model M680i and M685i Expansion Modules
245
MODEL M680I AND M685I EXPANSION MODULES
The 6873i IP phone offers two optional expansion modules that attach to the right side of the
phone to provide additional programmable keys.
The M680i provides 16 softkeys, with each softkey providing an LED for call status indication.
The M680i provides a paper label for convenient key labeling.
The M685i provides three pages of 28 softkeys (for a total of 84 programmable softkeys), with
each softkey providing an LED and graphical UI for call status indication. The M685i features
a 4.3” 480x272 pixel color backlit LCD display.
The M680i and M685i Expansion Module keys support the following functions:
Note:
The USB port on the 6873i will be disabled if the phone is being powered using
802.3af Power over Ethernet (PoE) and one or more expansion modules are connected.
Use the recommended AC adapter (optional accessory) or power the phone using 802.3at
PoE plus to ensure the USB port will be functional when expansion modules are connected
to the 6873i.
• None • Speed Dial/Conf
• Line • Speed Dial/MWI
• Speed Dial • Directory
• Do Not Disturb (DND) • Filter
• Busy Lamp Field (BLF) • Callers List
• BLF/List • Redial
• Auto Call Distribution (ACD) • Conference
• Extensible Markup Language (XML) • Transfer
• Flash • Intercom (Icom)
• Sprecode • Phone Lock
• Park • Paging
• Pickup • Login
• Last Call Return • Discreet Ringing
• Call Forward • Call History
M680i Expansion Module
M685i Expansion Module
