Mitel 6873i SIP Phone Release 4.2.0 SP2 User Guide
132
CONFIGURING A SPEED DIAL/MWI KEY USING THE MITEL WEB UI
1. Click on Operation > Softkeys and XML.
or
Click on Operation > Expansion Module <N>.
Softkeys
2. Select from Key 1 through Key 48 on the Top keys.
3. In the Type field, select Speed Dial/MWI.
4. In the Label field, enter a label to apply to this key. When messages are pending, the phone
UI will display the number of pending messages and the defined label.
5. In the Value field, enter call URI and voicemail URI separated by a semi-colon, as per the
following syntax: [call URI];[voicemail URI]. For example,
+33123456,,,3456#0000#@domain;sip:voicemail_peter@domain.
6. In the Line field, select the line for which you want to use the key functionality.
Valid values are:
• global
• 1 through 24
7. In the state fields, check (enable) or uncheck (disable) the states you want to apply to this
softkey.
Expansion Module Keys
8. Select from Key 1 through Key 16 (M680i) or Key 84 (M685i).
MITEL WEB UI
Notes:
1. As the example above illustrates, pauses and DTMF are supported for the call
URI.
2. Ensure that no spaces are added between the call URI and the voicemail URI
when defining the key value.
3. If only one URI is provided, the value will be used for the voicemail URI and the
call URI will be left as undefined.
