4 TEMPERATURE INPUT MODULE REPLACEMENT
4 - 11
A616TD Q64TD
Address
(hex)
Name Read/write
Address
(hex)
Name Read/write
B2 CH3 User range settings offset value
R/W
B3 CH3 User range settings gain value
B4 CH3 User range settings thermal(L)
EMF offset value(H)
B5
B6 CH3 User range settings thermal(L)
EMF gain value(H)
B7
B8 CH4 Factory default offset value
B9 CH4 Factory default gain value
BA CH4 User range settings offset value
BB CH4 User range settings gain value
BC CH4 User range settings thermal(L)
EMF offset value(H)
BD
BE CH 4 User range settings thermal(L)
EMF gain value(H)
BF
C0
System area (Not used) -
to
