5 MULTIPLEXER REPLACEMENT
5 - 11
*1 Analog output (voltage) to the A616AD, processing analog input values of the A60MX.
The I/O characteristics and the maximum resolution are to be the same as in the specifications of the A616AD as below.
Input Analog input range Maximum resolution Digital output value
Voltage (V)
0 to +10 2.5mV (1/4000)
0 to 4000
-2000 to 2000
0 to +5 1.25mV (1/4000)
+1 to +5 1.0mV (1/4000)
-10 to +10 5.0mV (1/4000)
-5 to +5 2.5mV (1/4000)
