7 POSITIONING MODULE REPLACEMENT
7 - 23
*1 Nos.1 to 100 data items/axis of positioning data can be set using the buffer memory and Nos.1 to 600 data/axis can be set
with QD75M.
The positioning data in the buffer memory is not backed up.
*2 The near pass function is valid only during the continuous path control. (AD75M: Selected with parameters, QD75M:
Standard function)
QD75M does not have address pass mode. If passing the positioning address, continue with continuous operation.
(However, it will stop once.)
*3 GX Configurator-QP is available with SW2D5C-QD75P or later version.
I/O points
32 points
(I/O assignment: special 32 points)
32 points
(I/O assignment: intelligent 32 points)
No. of module occupied slots 1 1
Weight 0.35kg 0.15kg 0.15kg 0.16kg
I/O signal for
external
devices
START signal × (integrated into CHG)
When using both the
speed-position
switching control and
the external start, input
the external start signal
to the interrupt module
and start using the
direct output.
CHG signal Speed-position switching signal
External command signal (External start or
speed-position switching selectable with
parameters)
peripheral
devices (data
setting, etc.)
Connection
with peripheral
devices
Direct connection
Connection via programmable controller
CPU, Q corresponding serial
communication module, Q corresponding
MELSECNET/H remote I/O module
The connecting shape
differs.
AD75TU Available Unavailable
×
AD75TU cannot be
used.
Use GX Configurator-
QP.
GX
Configurator
GX Configurator-AP
GX Configurator-QP
*3
Available GX
Configurator differs.
: Compatible, : Partial change required, ×: Incompatible
Model
Item
AD75M1 AD75M2 AD75M3 QD75M1 QD75M2 QD75M4
Compati-
bility
Precautions for
replacement
