(4) SF-PW module

This module supplies all DC current to the entire FR-SF.

AC170 to 253V

input

IEI

AC200

AC0

(Note) 1.

The blocks B, C, D, E, F, G, H, and I are power

supplies for the base amplifier of the main cir-

cuit power transistors_ Note that they are not

insulated from the main circuit.

The 0 V lines of the block A (DGA, AGA, D024) are

mutually connected.
