Alarm
uo.
Abbr.
Name
34
DP
DATA PARITY
35
36
46
52
57
DE
DATA ERROR
TE
TRANSFER ERROR
PE
PARAMETER ERROR
OPE
OPTION CARD ERROR
Description
Pl"CJ."ll
(Note)
Parity error occurs in bus linkage with the M300
series CNC.
A
In bus linkage with the M300 series CNC, the
shift command which exceeds the specific value
A
is issued from the CNC.
In the bus linkage with the M300 series CNC,
data is not correctly transferred.
A
A parameter value which exceeds the allowable
range is set.
(It is set when the power of
A
the controller is turned on.)
The ambient temperature is abnormal or the main
circuit devices are overheated because an
over-
A
load is applied or the air cooling fan stops.
The motor is overheated because an overload
is applied or the motor cooling blower stops.
lowing error exceeds the
sbecific
value.
In the bus linkage with the M300 series CNC,
any fault occurs in an other servo axis.
A
Any function which is not provided with the
option card is selected.
A
Motion A
-
The base shut-off occurs in the controller, the main circuit
COntaCtor
is
turned off,
and the motor stops in the free-run state.
In additon, the
trouble signal contacts FA-FC are open.
(Note)
For the main circuit contactor
: See Appendixes l-4 and l-5
(contact
MC11
For the trouble signal contacts FA and FC :
See Appendixes l-4 and 1-5
(CON1 pins 11 and
12)
-
22
-
