(4) Assemble the parts
in
the reverse order of
the disassembling pro-
cedures (1) to (3).
Fan
Finger
guard
/
lb)
(1)
In the case of 160
frames or more:
Remove the three hex.
socket bolts which
fasten the fan case
and pull the fan case
in the rear direction
and the fan case with
the cooling fan can
be dismounted.
(2) Remove the hex.
socket bolts which
fasten the finger
guard.
-
72
-
