Checking and

replacing parts

Adjusting and

re-

2.9 placing motor

built-

in encoder

(5) Apply screw lock paint on the sensor mounting screws and

plate mounting screws.

(6) When assembling the fan case,

fully extend the sensor leads

into the terminal box to prevent them from getting caught.
