Mitsubishi LANCER EVOLUTION-IV 1998

SINGLE PART INSTALLATION POSITION – Solenoid Valve
A
Intake manifold
stay
Secondary
air control
solenoid
valve
B
Fuel pressure
solenoid valve
C
Waste gate
solenoid valve
D
Rear combination
lamp (RH)
Direction valve
Proportioning
valve
C-16
SOLENOID VALVE
Name Symbol Name Symbol
Direction valve <vehicles with AYC> D Secondary air control solenoid valve A
Fuel pressure solenoid valve B Waste gate solenoid valve C
Proportioning valve <vehicles with AYC> D
