15-1
INTAKE AND
EXHAUST
CONTENTS
SERVICE SPECIFICATIONS 2. . . . . . . . . . . . . .
SPECIAL TOOL 2. . . . . . . . . . . . . . . . . . . . . . . . .
ON-VEHICLE SERVICE 2. . . . . . . . . . . . . . . . . .
1. Turbocharger Boost Pressure Check 2. . . .
2. Boost Pressure Control System Check 3. .
3. Wastegate Actuator Check 4. . . . . . . . . . . . .
4. Wastegate Solenoid Valve Check 4. . . . . . .
5. Air Bypass Valve Check 4. . . . . . . . . . . . . . .
6. Secondary Air Control System Check 5. . .
7. Secondary Air Control Solenoid Valve
Check 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8. Secondary Air Valve Check 6. . . . . . . . . . . .
9. Vacuum Tank Check 6. . . . . . . . . . . . . . . . . . .
INTERCOOLER 7. . . . . . . . . . . . . . . . . . . . . . . . . .
AIR CONTROL VALVE 8. . . . . . . . . . . . . . . . . . .
INTAKE MANIFOLD 9. . . . . . . . . . . . . . . . . . . . . .
EXHAUST MANIFOLD AND
TURBOCHARGER 11. . . . . . . . . . . . . . . . . . . . . .
EXHAUST PIPE AND MUFFLER 14. . . . . . . .
