REAR AXLE – Sensor Relay <Vehicles with AYC> / AYC-ECU
27-53
INSPECTION
1. LONGITUDINAL AND LATERAL ACCELERATION
SENSOR CHECK
Refer to GROUP 35B – Acceleration Sensor.
2. AYC RELAY CONTINUITY CHECK
Battery voltage Terminal No.
1 3 4 5
When not energized
When energized
AYC-ECU
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
D Front Floor Console Removal and Installation
Unit: Nm {kgf@m}
5 {0.5}
AYC-ECU
5 {0.5}
To Next Page
