Mitsubishi LANCER EVOLUTION-IV 1998

ENGINE – Crankshaft Oil Seal
11-15
CRANKSHAFT OIL SEAL
REMOVAL AND INSTALLATION
4
3
2
1
5
127 – 137
{13.0 – 14.0}
3
Unit: Nm {kgf@m}
Engine oil
5
Crankshaft front oil seal removal
steps
D Timing belt and timing belt B
(Refer to P.11-21.)
D Crank angle sensor
(Refer to GROUP 16.)
1. Crankshaft sprocket B
2. Key
"CA 3. Crankshaft front oil seal
Crankshaft rear oil seal removal
steps
D Transmission assembly
D Clutch cover and disc
AA""BA 4. Flywheel
"AA 5. Crankshaft rear oil seal
