MANUAL TRANSMISSION OVERHAUL – Control Housing
22B-40
"DA SPRING PIN INSTALLATION
"EA SPRING PIN INSTALLATION
"FA LOCK PIN INSTALLATION
Drive in the lock pin in the direction shown in the illustration.
Control shaft
Stopper body
Installation
direction
Slit
Spring pin
Spring pin
Lock pin
Control finger
