REAR AXLE Troubleshooting <AYC>
27-16
Code No. 72: Directional control valve (right) system Probable cause
This code is output when the directional control valve (right) control circuit is open-
or short-circuited.
D Defective directional control valve (right)
D Defective harness or connector
D Defective AYC-ECU
OK
Check and repair the harness between
directional control valve (right) and
body ground.
OK
Check the trouble symptom.
OK
Replace AYC-ECU.
NG
Check the harness between directional
control valve (right) and AYC-ECU.
NG
Repair
OK
Check the trouble symptom.
OK
Check the following connectors:
B-96, B-94, D-06, F-30, F-29
NG
Repair
OK
Measure at F-29 directional control
valve (right) connector.
D Disconnect the connector and
measure at the directional control
valve side.
D Continuity across 1 and body
ground
OK: Conducting
NG
Check the following connectors:
F-29, F-30
NG
Repair
Measure at F-29 directional control
valve (right) connector.
D Disconnect the connector and
measure at the directional control
valve side.
D Resistance across 1 2
OK: 19 21 or less
NG
Replace the hydraulic unit.
