3-68
Options
3Controller
■ Installation method
This is mounted on the control unit (RZ181/RZ326A/RZ327 card) in the controller.
Securely insert the pneumatic hand interface (2A-RZ365/375) into the CNHNDOUT/CNHND connector on the
control unit.
Fig.3-23 ： Installation of pneumatic hand interface(CR3-535M controller)
Control unit （RZ181 card）
＜RZ181＞
CNHNDOUT
CNHNDOUT
CNHND
CNHND
2A-RZ365
or
2A-RZ375
Jumper
