Mitsubishi MELSEC-F FX1N-40MT-001 User Manual

FX1N Series Programmable Controllers Introduction 1.
1-5
*1: Internal 24V DC
*2: The value depends on the switch setting.
Special function blocks
MODEL DESCRIPTION
NUMBER
OF I/O
POWER SUPPLY
DIMENSIONS
mm (inches)
MASS
(WEIGHT)
kg (lbs)
I O
Internal
5V DC
External
24V DC
FX2N-2DA Digital to analog converter - 8 - 30mA
85mA
*1
43
(1.7)
90
(3.5)
87
(3.4)
0.2(0.44)
FX2N-2AD Analog to digital converter - 8 - 20mA
50mA
*1
FX2N-4DA Digital to analog converter - 8 - 30mA 200mA
55
(2.1)
0.3(0.66)
FX2N-4AD Analog to digital converter - 8 - 30mA 55mA
FX2N-4AD-PT PT 100 probe interface - 8 - 30mA 50mA
FX2N-4AD-TC Thermo-couple interface - 8 - 30mA 50mA
FX2N-32CCL CC-Link Interface block - 8 - 130mA 50mA
43
(1.7)
0.2(0.44)
FX2N-16LNK-M
MELSEC-I/O LINK
Remote I/O system
master block
*2 8 *2 200mA 90mA 0.5(1.1)
FX0N-3A Analog / Digital converter - 8 - 30mA
90mA
*1
43
(1.7)
87
(3.4)
0.2(0.44)
FX2N-8AD Analog input block - 8 - 50mA 80mA
75
(3.0)
75
(3.0)
0.3(0.66)
