FX1N Series Programmable Controllers Power Supply 4.
4-4
4.5.2 DC Power supply
Power supply
Circuit protector or fuse
Ground
Input circuit power supply
Input switch
Input sensor (PNP open collector)
Fuse
DC/DC
Converter
+
-
24V
0V
S/S
X0
X1
S/S
X0
24+
24-
24V DC
Main Unit
Extension
block
Special function
block
+
