Inputs 5.
5-1
5. Inputs
5.1 24V DC input Specifications
FX1N main unit,
extension block
FX0N,FX2N Extension block
X0 à
àà
à X7 X10 à
àà
à
Input voltage 24V DC ±10%
Input current 24V DC, 7mA 24V DC, 5mA 24V DC, 5mA
Input switching
current
OFF à ON >4.5mA >3.5mA >3.5mA
ON à OFF <1.5mA
Response time 10ms
Variable response time X000-X007 0-15ms ---
Circuit isolation Photocoupler
Operation indication LED is lit
FX1N Series Programmable Controllers
