FX1N Series Programmable Controllers Installation Notes 3.
3-6
3.4 PLC Mounting Arrangements
To prevent a rise in temperature, mount the units to walls. Never mount them to the floor or
ceiling of an enclosure.
Below (left) Single row arrangement
Below (right) Double row arrangement using extension cable FX0N-65EC
(650mm (25.59 inches); supplied separately).
FX
1N
CPU
Function block
Function block
A
A
A
FX
0N
,FX
2N
Extension
blocks
A
A
A
> 50mm(1.97 inches)
A
A
FX
1N
CPU
Function block
Function block
A
A
AA
> 50mm(1.97 inches)
A
