FX1N Series Programmable Controllers Diagnostics 7.
7-8
7.9 Instruction List
0 1 2 3 4 5 6 7 8 9
000
Program Flow CJ CALL SRET IRET EI DI FEND WDT FOR NEXT
010 Transfers, Comp CMP ZCP MOV BMOV BCD BIN
020 + - x /, Logics ADD SUB MUL DIV INC DEC WAND WOR WXOR
030 Shift SFTR SFTL SFWR SFRD
040 Data Operation ZRST DECO ENCO
050 High Speed REF MTR HSCS HSCR SPD PLSY PWM PLSR
060 Handy Instructions IST ABSD INCD ALT RAMP
070 FX I/O Devices DSW SEGL FROM TO
080 FX Ser Devices RS PRUN ASCI HEX CCD VRRD VRSC PID
150 Positioning ABS ZRN PLSV DRVI DRVA
160 Real Time Clock TCMP TZCP TADD TSUB TRD TWR HOUR
170 Special Comms RD3A WR3A
220
In-line Compare
LD= LD> LD<
LD LD
230
LD
AND= AND> AND<
AND AND AND
240 OR= OR> OR<
OR OR OR
