FX1N Series Programmable Controllers Introduction 1.
1-11
1.4.1 Input/Output Points and Current Consumption
The following tables show the input/output points of various types of FX series extension
blocks, and special function blocks, along with the special function block current consumption.
.
*1:8 points are used for actual input/output, however, this block should occupy 16 input/output
points.
Extension blocks
MODEL
INPUT
X
OUTPUT
Y
TOTAL
FX0N-8ER-ES/UL 4(8) 4(8)
16
*1
FX0N-8EX-ES/UL 8 - 8
FX0N-8EX-UA1/UL 8 - 8
FX
0N-8EYR-ES/UL - 8 8
FX
0N-8EYT-ESS/UL - 8 8
FX
0N-16EX-ES/UL 16 - 16
FX0N-16EYT-ESS/UL - 16 16
FX0N-16EYR-ES/UL - 16 16
FX2N-16EX-ES/UL 16 - 16
FX
2N-16EYR-ES/UL - 16 16
FX
2N-16EYT-ESS/UL - 16 16
