FX1N Series Programmable Controllers Inputs 5.
5-3
5.1.2 Input Circuit Connection
FX1N Main unit
FX2N and FX0N Extension blocks
24V
X
24V DC
0V
S/S
Source (-ve S/S)
24V
X
24V DC
0V
S/S
Sink (+ve S/S)
S/S
X
Source
24V DC
±10%
4.3 k
Ω
S/S
X
Sink
24V DC
±10%
4.3 k
Ω
