Outputs 6.
6-1
6. Outputs
6.1 Output Specifications
Description Relay Output Transistor Output
Switched voltages
(resistive load)
≤ 240V AC, ≤ 30V DC 5-30V DC
Rated current / N points
(resistive load)
2A/1 point, 8A/COM 0.5A/1 point, 0.8A/COM
Max. Inductive load 80VA, 120/240V AC 12W/24V DC
Max. lamp load (tungsten
load)
100W (1.17A/85V AC, 0.4A/
250V AC)
1.5W/24V DC
Minimum load
When supply voltage < 5V
DC allow at least 2mA flow
------------------
Response time
(approx.)
OFF à
ON
10ms < 0.2ms; < 5µs (Y0,Y1 only)
ON à
OFF
10ms < 0.2ms (I > 0.2A); <5µs (Y0,Y1 only)
Circuit isolation By Relay PhotoCoupler
Open circuit current
leakage
---------------- 0.1mA/30V DC
Operation indication LED is lit when coil is energized
FX1N Series Programmable Controllers
