FX1N Series Programmable Controllers Power Supply 4.
4-2
*1 Includes the input current (7 or 5 mA per point).
DC Power Supply Units
4.4 Power Requirements
AC Power Supply Units
FX1N-14M FX1N-24M FX1N-40M FX1N-60M
Power supply 100 - 240V AC +10%, -15%, 50-60Hz
Max. allowable momentary power
failure period
10ms; If less than 10ms, the PLC will continue operation.
Fuse (size) rating 250V 1A 250V 3.15A (3A)
In-rush current
100V AC - Max. 15A for 5ms
200V AV - Max. 25A for 5ms
Power consumption *1 29W 30W 32W 35W
FX1N-14M FX1N-24M FX1N-40M FX1N-60M
Power supply 24V DC +20% ~ 12V DC -15% (28.8 ~ 10.2V DC)
Max. allowable momentary power
failure period
5ms; If less than 5ms, the PLC will continue operation.
Fuse (size) rating 125 V 3.15A
In-rush current
24V DC - Max. 25A for 1ms
12V DV - Max. 22A for 0.3ms
Power consumption 13W 15W 18W 20W
