FX1N Series Programmable Controllers Inputs 5.
5-4
5.1.3 Diodes and Inputs Connected in Series
Vdrop across the diode Max. 4V
No more than 2 LEDs should be connected in series.
FX
0N,
FX
2N
Extention block
X
S/S
24V
X
0V
S/S
FX
1N
