FX1N Series Programmable Controllers Diagnostics 7.
7-11
7.10 Device List
Item Specification Remarks
Program capacity 8K steps Provided by built in EEPROM memory
I/O configuration
Max hardware I/O configuration points 128, dependent on user selection
(Max. software addressable Inputs 128, Outputs 128)
Auxiliary
relay
(M coils)
General 384 points M0 to M383
Latched 1152 points (subset) M384 to M1535
Special 256 points From the range M8000 to M8255
State relays
(S coils)
Latched 1000 points S0 to S999
Initial 10 points (subset) S0 to S9
Timers (T)
100 ms
Range: 0.1 to 3,276.7 s
200 points
T0 to T199
10 ms
Range: 0.01 to 327.67 s
46 points
T200 to T245
1ms
retentive
Range: 0.001 to 32.767 s
4point
T246 to T249
100 ms
retentive
Range: 0.1 to 3,276.7 s
6 points
T250 to T255
