12
TROUBLESHOOTING
12.3 Error Code List
12.3.4 Error code list (2000 to 2999)
12 - 31
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
2112
• The module other than intelligent
function module is specified by the
intelligent function module dedicated
instruction.
Or, it is not the corresponding
intelligent function module.
• There is no network No. specified by
the network dedicated instruction.
Or the relay target network does not
exit.
Read the individual information of the
error using GX Developer, check and
correct the intelligent function module
dedicated instruction corresponding to
its value (program error location).
QS
2124
• A module is installed to the actual I/O
points or greater.
• A module is installed to the slot
whose assigned I/O range includes
the limit of actual I/O points.
• Remove the module installed to the
actual I/O points or greater.
• Reset the I/O assignment setting of
the parameter so as not to exceed the
actual I/O points.
QS
2125
• A module that the safety CPU module
cannot recognize has been mounted.
• There was no response from the
intelligent function module.
• Mount a module supported in the
safety CPU module.
• The intelligent function module is
experiencing a hardware fault.
(Contact your local Mitsubishi
representative.)
QS
2200
There is no parameter file at the
program memory.
Set the parameter file to the program
memory.
QS
2210
The contents of the boot file are
incorrect.
Check the boot setting. QS
Error
Code
(SD0)
Error Contents and Cause Corrective Action
Corresponding
CPU
