Appendix 2 Safety CPU Module Upgrade
APPENDICES
Appendix 2 Safety CPU Module Upgrade
(1) Additional functions and availability of the functions according to the version of
GX Developer
TableApp.1 Additional functions and availability of the functions according to the version of GX Developer
New function
Compatible
function version
Compatible serial No.
Compatible GX
Developer
Response performance enhancement( CC-
Link Safety System Master Module User's Manual)
A 10032 or later
Version 8.65T
or later
CC-Link IE controller network compatibility (
CC-Link IE Controller Network Reference Manual)
MELSECNET/H transient transmission function
( Q Corresponding MELSECNET/H Network
System Reference Manual (PLC to PLC network))
Ethernet compatibility( Q Corresponding
Ethernet Interface Module User's Manual (Basic)),
( Q Corresponding Ethernet Interface Module
User's Manual (Application))
Dedicated instruction compatibility ( QSCPU
User's Manual (Function Explanation, Program
Fundamentals)), ( CC-Link IE Controller
Network Reference Manual), ( Q
Corresponding MELSECNET/H Network System
Reference Manual (PLC to PLC network)), (
Q Corresponding Ethernet Interface Module User's
Manual (Basic)), ( Q Corresponding Ethernet
Interface Module User's Manual (Application))
MC protocol( Q Corresponding MELSEC
Communication Protocol Reference Manual)
Clock data change function using special relay and
special registers ( QSCPU User's Manual
(Function Explanation, Program Fundamentals))
Remote password setting function ( QSCPU
User's Manual (Function Explanation, Program
Fundamentals))

Mitsubishi MELSEC Specifications

General

Category	Programmable Logic Controller (PLC)
Manufacturer	Mitsubishi Electric
Series	MELSEC
Programming Languages	Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), Sequential Function Chart (SFC)
Communication Protocols	Ethernet, CC-Link, RS-232, RS-485, USB, Profibus, Modbus
Model Series	FX, Q, L, iQ-R, iQ-F
Input Voltage	100-240V AC, 24V DC (varies by model)
Memory Capacity	Varies widely depending on the CPU module and series. Ranges from kilobytes to megabytes.
I/O Points	16 to 8192 points (varies by model)
Communication Ports	Ethernet, RS-232, RS-485, USB (varies by model)
Programming Software	GX Works2, GX Works3, GX Developer
Operating Temperature	0°C to 55°C
Storage Temperature	-25°C to 75°C
Humidity	5% to 95% (non-condensing)
Vibration Resistance	10 to 57Hz, 0.075mm amplitude; 57 to 150Hz, 9.8m/s² acceleration
Shock Resistance	147m/s², 3 times in each direction (X, Y, Z)
Protection Class	IP20 (varies by model)
CPU Processing Speed	0.02μs to 0.1μs per instruction (varies by model)
