12.3 Error Code List
12.3.4 Error code list (2000 to 2999)
12
TROUBLESHOOTING
12.3.4 Error code list (2000 to 2999)
The following shows the error messages from the error code 2000 to 2999, the contents
and causes of the errors, and the corrective actions for the errors.
Table12.3 Error code
Error
Code
(SD0)
Error
Message
Common
Information
(SD5 to 15)
Individual
Information
(SD16 to 26)
LED Status CPU
Operation
Status
Diagnostic
Timing
RUN ERROR
2000
MODULE
VERIFY
ERROR
Module No. – Off Flash Stop
When an END
instruction
executed.
2100
MODULE
LAYOUT
ERROR
Module No. – Off Flash Stop
At power ON/
At reset
2106
MODULE
LAYOUT
ERROR
Module No. – Off Flash Stop
At power ON/
At reset
2107
MODULE
LAYOUT
ERROR
Module No. – Off Flash Stop
At power ON/
At reset
