5.3 Names of Parts and Settings
5
POWER SUPPLY MODULE
5.3 Names of Parts and Settings
The names of the parts of each power supply module are described below.
Figure 5.1 Power supply module
QS061P-A1
POWER
QS061P-A1
POWER
1)7)
8)
4)
3)
2)
6)
5)
9),10)
<For QS061P-A1>
QS061P-A2 200 to 240VAC input, 5VDC 6A output
QS061P-A1 100 to 120VAC input, 5VDC 6A output
