1
OVERVIEW
1.1 Features
1 - 3
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
GENERAL SPECIFICATIONS
4
CPU MODULE
5
POWER SUPPLY MODULE
6
BASE UNIT
7
BATTERY
8
CPU MODULE START- UP PROCEDURES
1.1 Features
The QS series CPU module has the following new features:
(1) Safety PLC system can be constructed
The QS series programmable controllers have obtained the highest safety level
(IEC61508 SIL3, EN954-1/ISO13849-1 Category 4, IEC62061) applicable to
programmable controllers.
* 1 : The available functions vary depending on the versions. For details, refer to Appendix 2.
Figure 1.1 Safety PLC system
CC-Link Safety
CC-Link Safety remote I/O station
Standard remote I/O station
Standard Remote device station
CC-Link Safety
remote I/O station
CC-Link Safety
remote I/O station
Power supply/CPU/CC-Link Safety master module
GX Developer
(Version 8.40S or later)*1
Emergency stop switch
Light curtain
Emergency stop switch
Safety relay

Mitsubishi MELSEC Specifications

General

Category	Programmable Logic Controller (PLC)
Manufacturer	Mitsubishi Electric
Series	MELSEC
Programming Languages	Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), Sequential Function Chart (SFC)
Communication Protocols	Ethernet, CC-Link, RS-232, RS-485, USB, Profibus, Modbus
Model Series	FX, Q, L, iQ-R, iQ-F
Input Voltage	100-240V AC, 24V DC (varies by model)
Memory Capacity	Varies widely depending on the CPU module and series. Ranges from kilobytes to megabytes.
I/O Points	16 to 8192 points (varies by model)
Communication Ports	Ethernet, RS-232, RS-485, USB (varies by model)
Programming Software	GX Works2, GX Works3, GX Developer
Operating Temperature	0°C to 55°C
Storage Temperature	-25°C to 75°C
Humidity	5% to 95% (non-condensing)
Vibration Resistance	10 to 57Hz, 0.075mm amplitude; 57 to 150Hz, 9.8m/s² acceleration
Shock Resistance	147m/s², 3 times in each direction (X, Y, Z)
Protection Class	IP20 (varies by model)
CPU Processing Speed	0.02μs to 0.1μs per instruction (varies by model)
