TROUBLESHOOTING
12.3 Error Code List
12.3.5 Error code list (3000 to 3999)
12 - 37
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
* 3: MELSECNET/H modules whose serial number (first five digits) is “08102” or higher are targeted.
3100
• The number of modules actually
mounted is different from that is set in
Network parameter for CC-Link IE
controller network.
• The start I/O number of the module
actually mounted is different from that
is set in Network parameter for
CCLink IE controller network.
• Some data in the parameters are not
supported.
• The station type for a CC-Link IE
controller network has been changed
while the power is ON.
(RESET RUN is required to
change the station type.)
• Check the setting in Network
parameter and actual mounting
status, and if they differ, correct either
the setting or mounting status so that
they become the same. If the
parameter setting is corrected, write
Network parameter to the CPU
module.
• If an error occurs even after
correction, a hardware failure is
considered. (Please consult your
local Mitsubishi representative.)
QS
• The number of modules actually
mounted is different from that is set in
Network parameter for MELSECNET/
H.
• The start I/O number of the module .
actually mounted is different from
thatis set in Network parameter for
MELSECNET/H.
• Some data in the parameters are not
supported.
• The station type for a MELSECNET/H
has been changedwhile the power is
ON.
(RESET RUN is required to
change the station type.)
• The mode switches of MELSECNET/
H module are out of the setting range.
Check the setting in Network parameter
and actual mounting status, and if they
differ, correct either the setting or
mounting status so that they become
the same. If the parameter setting is
corrected, write Network parameter to
the CPU module.
If an error occurs even after correction,
a hardware failure is considered.
(Please consult your local Mitsubishi
representative.)
Set the mode switches of
MELSECNET/H module within the
setting range.
QS
3101
The refresh parameter for CC-Link IE
controller network is out of the setting
range.
Check the setting in Network parameter
and actual mounting status, and if they
differ, correct either the setting or
mounting status so that they become
the same. If the parameter setting is
corrected, write Network parameter to
the CPU module.
QS
• The start I/O number of the module
actually mounted is different from that
is set in Network parameter.
• The refresh parameter for
MELSECNET/H is out of the setting
range.
Error
Code
(SD0)
Error Contents and Cause Corrective Action
Corresponding
CPU
