12
TROUBLESHOOTING
12.3 Error Code List
12.3.5 Error code list (3000 to 3999)
12 - 41
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
3106
• The network refresh parameter for
CC-Link is out of range.
• Although the safety remote station set
in the network parameter does not
support the safety data monitoring
time, it is set for the station.
• Check the parameter setting.
• Check the [Model name] and [Module
technical version] of the safety
remote station settings, or delete the
setting of the safety data monitoring
time.
QS
The safety data monitoring time has
been set.
Delete the setting of the safety data
monitoring time.
QS
*1
3107
The CC-Link parameter setting is
incorrect.
Check the parameter setting. QS
3400
The start I/O number of the target
module in Remote password is set to
other than 0
H to 3E0H.
Change the start I/O number of the
target module to the number within 0
H to
3E0
H.
QS
3401
Ethernet module of function version B
or later is not mounted on the slot
specified for the start I/O number of
Remote password.
Mount the Ethernet module of function
version B or later on the slot specified
for the start I/O number of Remote
password.
QS
Error
Code
(SD0)
Error Contents and Cause Corrective Action
Corresponding
CPU
* 1: For the module whose first five digits of serial number are “10031” or earlier.
